| Rám |
Hydroformed & Butted Speed Metal™ Aluminum (TT/DT) Frame, w/ Triple Triangle™, Replaceable Derailleur Hanger, Disc Brake Mounts, and Zerostack 1 1/8" Head Tube, 650B Design |
| Vidlice |
Rock Shox XC32 TK Coil 27.5" w/100mm Travel, w/Turn Key Lockout, QR Droupout, Coil Spring, Disc Only Lower, W/1.125" Alloy Steerer, W/ Remote Poplock Lockout |
| Tlumič |
|
| Kliky |
Shimano Deore, FC-M610, 42/32/24T |
| Středové složení |
Shimano included in FC |
| Řazení |
Shimano Deore SL-M610 |
| Kazeta |
Shimano CS-HG50-10, 11-36T, 10-Speed |
| Řetěz |
KMC X10 |
| Přesmykač |
Shimano Deore, FD-M610 |
| Přehazovačka |
Shimano Deore XT Shadow Plus, RD-M786 |
| Ráfky |
Jalco JD200, Double Wall, 32H |
| Náboje |
All Terra Alloy Disc, W/ Quick Release, Center Lock |
| Pedály |
N/A |
| Brzdy |
Shimano BR-M396, Hydraulic Disc, W/ 160mm Rotor SM-RT30 |
| Představec |
All Terra 1 1/8" Threadless, 3D Forged, 4-Bolt W/ CNC Face Plate, 6° Rise, 31.8mm Clamp |
| Hlavové složení |
Kore 1B-1 1 1/8" Threadless, Zerostack |
| Brzdové páky |
Shimano Hydraulic Disc Brake Lever |
| Dráty |
14G Stainless |
| Sedlo |
All Terra Colorado |
| Sedlovka |
All Terra Alloy Micro-Adjust, 30.9mm |
| Extra |
|
| Pláště |
WTB NANO 2.1 |
