| Rám |
COR Trail Philosophy, FOC Ultra Carbon Frame, 130mm Travel A.O.S. Suspension System w/ Forged Linkage, Pivots, 1.5" to 1 1/8" Integrated Head Tube, & 12x142mm Maxle Dropouts |
| Vidlice |
Fox 32 FLOAT 27.5 CTD FIT w/ Adjust, 130mm Travel, 15QR, w/ FIT Damper, Lockout & Rebound Adjust, Tapered Alloy Steerer |
| Tlumič |
Fox Racing Shox Float CTD BV w/ Adjust, 7.25"x1.75" Air Shock, w/ Rebound Adjust & Lockout |
| Kliky |
RaceFace Turbine, 42/32/22T, 3x10 |
| Středové složení |
RaceFace |
| Pedály |
N/A |
| Přesmykač |
Shimano Deore XT, FD-M781-D |
| Přehazovačka |
Shimano Deore XT Shadow Plus, Direct Mount, RD-M786-D |
| Řazení |
Shimano Deore XT, SL-M780, Rapid Fire |
| Kazeta |
Shimano Deore XT, CS-M771-10, 10-Speed, 11-36T |
| Řetěz |
KMC X10 |
| Ráfky |
e.thirteen TRS+ Alloy 650b Wheelset |
| Pláště |
Continental X-King 27.5x2.4", ProTection Folding |
| Náboje |
(F) e.thirteen TRS+ Alloy 650b Wheelset, 15x100mm Thru Axle, (R) e.thirteen TRS+ Alloy 650b Wheelset, 12x142mm Thru Axle |
| Dráty |
e.thirteen TRS+ Alloy 650b Wheelset |
| Brzdy |
Formula T1, w/ 180mm Alloy Carrier Rotor (F/R) |
| Brzdové páky |
Formula T1, w/ TFRA & FCS |
| Představec |
Thomson Elite X4, 1-1/8" Threadless, 5° Rise, 31.8mm Clamp, 80mm |
| Hlavové složení |
Orbit C-40-ACB |
| Sedlo |
fizik Tundra2 mg |
| Sedlovka |
RockShox Reverb Stealth, 34.9mm |
| Extra |
|
| Barvy |
raw/white/blue |
